1353M - DUAL - TACK BORDER HANDLE TACKER

Features

    • Stainless steel top with ends folded down supports border for ease of handle loading

    • Accommodates various handle sizes

    • Unique fold rods on end of tooling allow for handle to be quickly folded in place without prior preparation

    • Tooling, combined with increased sew field allow both sides of handle to be efficiently sewn in place

    • Touch screen handle tack programming allows specialized stitching for certain handles

    • Operators can sit or stand at workstation

    • Border guides ensure the handle is centered on border

    • Stand with casters for easy location/ re-location within plant

    • Pedal operation keeps operators' hands free to work with border

Technical Features

    Max sewing speed (rpm) : 2500
    Factory preset speed (rpm) : 1800
    Sewing field (mm) : 250 x 160
    Needle system : SN135X1722
    Needle size : 22-140
    Weight of material : MEDIUM / HEAVY
    Max presser footlift (inch) : 19/32
    Sewing area (inch) : 9.8 X 6.3
    Voltage (v/ph/hz) : 220 1P 60HZ
    Current (amps) : 5
    Motor type : SERVO
    Air pressure (psi) : 80
    Air consumption (cfm) : 1
    Shipping weight (lbs) : 1300
    Shipping dimensions (w/l/h, inch) : 72 x 64 x 69
