4500 - SINGLE LANE BORDER QUILTER

Features

    • Automatic Programmable Border Workstation
    • State-of-the-art servo drives and advanced motion controller
    • Multi-needle sewing head with 65 needles ¼” spacing, 16” max stitch width
    • Virtually unlimited pattern design storage
    • Adjustable tension rewinder
    • Borders up to 18”
    • Patterns may be scaled, shifted or offset on-the-fly
    • Dual pattern stitching heads

Technical Features

    Factory preset multi-needle speed (rpm) : 1200
    Factory preset pattern sew head speed (rpm) : 3000
    Max stitch length (spi) : 5
    Max border width, finished (inch) : 18
    Voltage (v/ph/hz) : 220V 3PH 60HZ
    Current (amps) : 30
    Motor type : AC Servo
    Air pressure (psi) : 60
