BK-10-20 COMPUTERIZED QUILTING MACHINE
Features
• Suitable for mattresses, quilt covers and mattress toppers
• Simple operation and automatic control
• Independent sewing heads driven by servo motors
• Heavy duty stitching easily cope with heavy materials
• Excellent performance on a very wide range of materials
• User friendly programming and diagnostics
• Simple pattern selection with clear interactive touch screen
• Wide variety of patterns
• Pattern program
• Exact thread break restart point
Technical Features
• Output Capacity(stitches/minute) : 2400
• Stitch Lenght : 3-10 mm
• Sewing Area : 2200x2400 mm
• Total area required : 5500x9000 mm
• Servo Motor : AC x4
• Number of Sewing Head : 2
• Sewing Head : Modified Newlong DD-5
• Type of Stitch : Lockstitch
• Stitching Thickness : up to 2.2kg per m2
• Air Pressure : 6 BAR
• Weight : 2078 kg
• Power : 380 V 3 faz 4.5 KW
Brochure
Technical Specs
Video
