MN-50 MULTI NEEDLE QUILTING MACHINE
Features
• High speed up to 1.250 rpm, chain stitch multi needle quilting machine
• Automatic pressure roller gap adjustment for different fabric thickness
• Automatic break detection and step-by-step quilting embroidery function
• Pneumatic thread trimming technology for rapid cutting
• Full automatic sewing system integrable with panel cutting process in single cycle
• Widescreen user friendly touchscreen panel for all machine settings
• 6 axis servo motor control system for accurate and precise operation
• Ease of use, stable running and high precision quilting.
• Enhanced double bearing pin row bar
• Heavy duty shock absorber hopper balance system
• Robust structure with low noise and vibration
• Robust structure with low noise and vibrationWide variety of pattern options
including 360 and 180 degrees, storage up to 2.000 patterns
Technical Features
• Needle space : 25.4 mm
• Needle Type : 120/21, 140/22, 160/23,180/24
• Witdh : 100 - 2500 mm
• Weight : 4500 Kg
• Power : 7 KW
• Voltage : 380V 50HZ / 220V 60HZ
• Size : 5340 x 1500 x 2098mm
• Stitch size : 2 - 7 mm
• Quilting Thickness : ≤80 mm
• Rotation Speed : 600-1200 rpm
• Production Speed : 80-230 m/h
Brochure
Technical Specs
Video
