Technical Features

	BH-30	BH-40	BH-50
Spring Type:		Bonell
Number of Convolution:		4
Spring Height:	80-100 mm	80-100 mm	80-100 mm
Number of Convolution:		5
Spring Height:	130-150 mm	130-150 mm	130-150 mm
Number of Convolution:		6
Spring Height:	160-170 mm	160-170 mm	160-170 mm
End Coil Outside Diameter:	68-86 mm	84-96 mm	76-80 mm / 80-86 mm
Wire Diameter:	1.9-2.2 mm	1.9-2.4 mm	1.9-2.2 mm / 1.9-2.4 mm
Speed Control:	Frequency	modulation adjustable	at any time
Main Motor Control:		2.2 KW
Swift Motor Power:		1.1 KW
Heat Treatment Power:		10 KW
Heat Treatment Control:		Electronic Switching
Weight:		2906 kg
Max. Weight of Wire Roll:		900 kg
Power:		380 V 3 faz 80 A
Total Area:		5200 x 1700 mm
