Technical Features


Speed: 80 springs per minute depending on wire and fabric quality
Wire Diameter: 1.30 – 2.00 mm
Spring Central Diameter: 42-55 mm
Operation mode: Continuous or adjustable for required coil count
Welding unit: Ultrasonic welding system
Controls: Motion controller, PLC control, frequency inverters and touchscreen control panel
Max. Wire swift for reels: 1.000 kg.
Spring height outside fabric: 130-210 mm
Spring pocketed height: 100-180 mm
Fabric roll width: up to 800 mm
Spring type: Barrel or cylindrical
Speed control: Electronic
Main motor control: 8 x brushless servo motor
Swift motor power: 1.1 Kw
Air consumprion: 800 lt./min.
Heat treatment control: Electronic switching
Power: 380 V 3 phases 50 hertz 18 Kw
Weight: 3.747 kg.
Total Area required: 6250 x 2900 mm
***Automatic cutting device
