P. 89

3200PB





        Technical Information                                   Teknik Bilgiler

        OPERATION                                               OPERASYON
        Operator loads workstation with roll of border, enters size   Operatör makinaya bir rulo bordür yükler, gereken boyut
        and quantity needed. Workstation automatically measures   ve miktarı girer.Makina otomatik olarak doğru uzunluğu
        correct length and cuts border to size                  ölçer ve bordürü istenen boyuta getirir.

        OPTIONS                                                 SEÇENEKLER
        •  3200PMD - Marking module, 1 pen, extended mount
        •  3200PM4A - Marking module, 4 pen, for Size ID        •  3200PMD - Markalama modülü, 1 kalem,
                                                                   uzatılmış montaj
        MODEL                                                   •  3200PM4A - Markalama modülü, 4 kalem, Boyut
        •  33200PB1 - Border Measure and Cut with                  tanımlama için
           Pre-Feed Station
        •  33200PB1E - Border Measure and Cut w/o               MODEL
           Pre-Feed Station                                     •  33200PB1 - Bordür Ölçme ve Kesme, Ön besleme ünitesi
        •  33200PBTL - Border Measure and Cut with              •  33200PB1E - Bordür Ölçme ve Kesme
           Pre-Feed Station and Thermal Label                   •  33200PBTL - Bordür Ölçme ve Kesme, Ön besleme
                                                                   ünitesi, Termal etiket






                                                                                Mattress with    Foundation with
                                                                                Plain Border      Plain Border
                                                                           Düz bordürlü     Düz bordürlü
                                                                            yatak            baza




                                                                                               Footprint
                                                                                            Makina Yerleşim

       33200PBTL                                                                                122” / 310cm
       Border Measure and Cut  Pre-Feed Station and Thermal Label
      Bordür Ölçme ve Kesme, Ön besleme ünitesi, Termal etiket                    42” / 107cm


                                                                                              33200PB1
       SPECIFICATIONS / ÖZELLİKLER          33200PB1      33200PB1E  33200PBTL
       Weight of material / Malzeme tipi               LIGHT / MEDIUM
       Voltage (v/ph/hz) / Voltaj (v/ph/hz)            220V 1PH 60HZ                           72” / 183cm
       Current (amps) / Akım (amper)                 5                  10
       Motor type / Motor tipi                           EFKA DC                   42” / 107cm
       Air pressure (psi) / Hava basıncı (psi)             80
       Air consumption (cfm) / Hava tüketimi (cfm)   5                   6                   33200PB1E
                                                                        900
       Shipping weight (lbs) / Nakliye ağırlığı (lbs)   885  450
                                                                        705
                                                                                                   173” / 440cm
       Shipping dimensions (w/l/h, inch)    96 x 48 x 48  60 x 48 x 48  96 x 60 x 48
       Nakliye ebatları (w/l/h, inch)                                 40 x 59 x70
                                                                                  43” / 109cm
       PRODUCTION / ÜRETİM
       Borders per hr / Saatte bordür üretimi      150 - 180          100 - 120               33200PBTL

              PATENTS:  Our equipment may be covered by one or more patents. Please go to the following web page for an up-to-date patent list: www.atlatt.com/patents      © 2020 Atlanta Attachment Co.     19189010120
