Border Closer / Cerradora de borde Overlock / Sobrehilado
4300B
Technical Information Teknik Bilgiler
OPTIONS SEÇENEKLER
• 4300200 - Closer Station • 4300200 - Kapama İstasyonu
• 1330200 - Re-winder • 1330200 - Geri Sarma
• MMSPOOL - Plastic Spool • MMSPOOL - Plastik Makara
• 4300320 - Marking Module, right • 4300320 - Makara Modülü, Sağ
• 4300325 - Marking Module, left • 4300325 - Markalama Modülü, Sol
MODEL MODEL
• 4300B - Min. 8.5” • 4300B - Minimum 22cm
• 4300BN - Min. 6.5”, overlock only • 4300BN - Minimum 17cm, Sadece Overlok
• 4300BNN - Min. 5”, overlock only • 4300BNN - Minimum 13cm, Sadece Overlok
4300200 1330200
Closer (optional) Rewinder (optional)
Kapama (opsiyonel) Geri Sarma (Opsiyonel)
Closer Overlock
SPECIFICATIONS /ÖZELLİKLER Kapama Overlok
Max sewing speed (rpm) / Maksimum dikiş hızı (rpm) 5000 6000
Factory preset speed (rpm) / Fabrika ayarlı hız (rpm) 1800 ± 5% 5000 ± 5% 166"
Max stitch length (spi) / Maksimum dikiş uzunluğu (spi) 6 6
Needle system / İğne sistemi SNDLX1140 SNB27140
Needle size / İğne ölçüsü 22-140 81"
Weight of material / Malzeme tipi MEDIUM
Voltage (v/ph/hz) / Voltaj (v/ph/hz) 220V 1PH 60HZ
Current (amps) / Akım (amper) 15 Footprint
Motor type / Motor tipi EFKA DC SERVO Makina Yerleşim
Air pressure (psi) / Hava basıncı (psiI) 80
Air consumption (scfm) / Hava tüketimi (scfm) 14
Shipping Weight (lbs) / Nakliye ağırlığı (lbs) 2200
PRODUCTION / ÜRETİM
Pieces per hr (with 4 handles) / Saatte üretilen adet (4kulplu) 120
Pieces per hr with closer (with 4 handles) / 40
Kapama ile saatte üretilen adet (4 kulplu)
